UEDIN · 3867
Saxie. Nominal pitch: lowest note D₄.
Zoom with the + and − buttons, a double-click, a pinch, or Ctrl + mouse wheel.
Description
Technical description: Body of lacquered brass. Curved alto saxophone shaped body in one piece with six finger-holes and two keys. Two diametrically opposed vent holes on either side of the instrument just above u-bend. Wooden single reed mouthpiece with brass ligature band. Curved brass thumb|rest and loop for attaching a strap. L0: octave key. L1: T (B₄). L2: T (A₄). L3: T (G₄). R1: T (F₄). R2: T (E₄). R3: T (D₄). R4: key for F♯₄, D♯₅ and F♯₅. Keyhead type: modern. Keymount type: pillars with adjustable screw and torsion spring on either side of the key. Overall size: 492. Sounding length: from top of mouthpiece to middle of vent holes: 421. Bore: at top 8.6; bell diameter: 98.4. Inscription: "COUESNON & CIE / - PARIS - / CHATEAU THIERRY / FRANCE / = SAXIE = / U.S. PATENTN JUNE 3RD 1924 / -BTE S.G.D.G - ". General literature references: Rycroft 1999.
Measurements
492.
